金属粉末

KOS粉末はAM(3Dプリント)に最適化された高品質の粉末を供給しており、
お客様のオーダーメイド生産により、様々なニーズに対応できるよう努力しております。

  • EIGA
  • Titanium Alloys
  • Nickel Alloys
  • Stainless Steels

KOSはEIGA(Electrode Induction Melting Inert Gas Atomization)方式で生産された高品質の粉末を提供します。

特性

高純度の球刑化粉末を提供します。

粉末は最適な粒度分布で管理します。

反応性金属(Ti, Zr等)の粉末生産が可能です。

製品仕様

PBF (Powder Bed Fusion) : 10~53㎛

PBF-EBM (Powder bed fusion - Electron beam) : 45~150㎛

DED (Directed energy deposition) : 45~150㎛

Etc. (他のAMプロセスに適切なカスタマイズされた粉末サイズ)

粉末品質管理項目

Chemical composition

Particle size distribution by sieving (ASTM B214)

Particle size distribution by laser diffraction (ASTM B822)

Apparent / Tap density (ASTM B212 / ASTM B527)

Flowability (ASTM B213 and ASTM B964)

Powder Imaging (SEM)

Powder Cross-Section/Porosity Imaging (OM or SEM)

適用分野 : ADDITIVE MANUFACTURING(AM), METAL INJECTION MOLDING(MIM), THERMAL SPRAY(TSA)



Ti Gr.2

鋼種
成分
C O N H Fe
TI-2 Max 0.08 Max 0.25 Max 0.03 Max 0.015 Max 0.30

Specifications : ATSM B348, ASTM F67

Ti Gr.5

鋼種
成分
C O N H Fe AI V Y
TI-5 Max 0.08 Max 0.20 Max 0.05 Max 0.015 Max 0.30 5.5 - 6.75 3.5 - 4.5 Max. 0.005

Specifications : ASTM B348, ASTM F2924

Ti Gr.23

鋼種
成分
C O N H Fe AI V Y
TI-23 Max 0.08 Max 0.13 Max 0.05 Max 0.012 Max 0.25 5.5 - 6.5 3.5 - 4.5 Max. 0.005

Specifications : ASTM B348, ASTM F3001

Size

0~15㎛, 15~45㎛, 15~53㎛, 45~106㎛, 45~150㎛, Etc. (Customized powder size for other Additive Manufacturing process)

SEM image (Ti Gr.23 15~45㎛)

  • x200

  • x500

応用分野:エアロスペース、医療機器

包装:2.5kg



ALY718 (IN718)

鋼種
成分
C Mn Si P S Cr Co Mo Nb+Ta Ti Al B Fe Cu Ni
ALY718 Max 0.08 Max 0.35 Max 0.35 Max 0.015 Max 0.015 17.0 - 21.0 Max 1.0 2.80 - 3.30 4.75 - 5.50 0.65 - 1.15 0.20 - 0.80 Max 0.006 Re - mainder Max 0.30 50.0 - 55.0

Specifications : ASTM B637, ASTM F3055

ALY625 (IN625)

鋼種
成分
C Mn Si P S Cr Co Mo Nb Ti Al Fe Ni
ALY625 Max 0.10 Max 0.50 Max 0.50 Max 0.015 Max 0.015 20.0 - 23.0 Max 1.0 8.0 - 10.0 3.15 - 4.15 Max 0.40 Max 0.40 Max 5.00 Re - mainder

Specifications : ASTM B446, ASTM F3056

Size

0~15㎛, 15~45㎛, 15~53㎛, 45~106㎛, 45~150㎛, Etc. (Customized powder size for other Additive Manufacturing process)

SEM image (ALY718 15~45㎛)

  • x200

  • x500

応用分野:エアロスペース、海洋

包装 : 5.0kg



316L

鋼種
成分
Cr Ni Mo Mn S C P N Si Fe
316L 16.0 - 18.0 10.0 - 14.0 2.0 - 3.0 Max. 2.00 Max 0.03 Max. 0.03 Max. 0.045 - Max. 1.00 Bal.

Specifications : ASTM A479, ASTM F3184

630 (17-4PH)

鋼種
成分
C Cr Ni Mn Si P S Cu Nb+Ta Fe
630 Max. 0.07 15.0 - 17.5 3.0 - 5.0 Max. 1.00 Max 1.00 Max. 0.040 Max. 0.03 3.0 - 5.0 0.15-0.45 Bal.

Specifications : ASTM A564

Size

0~15㎛, 15~45㎛, 15~53㎛, 45~106㎛, 45~150㎛, Etc. (Customized powder size for other Additive Manufacturing process)

SEM image (316L 15~45㎛)

  • x200

  • x500

応用分野:自動車、海洋

包装 : 5.0kg
